Product information

High insertion loss over a broad frequency range
Optimised against interferences in the lower frequencies
Suitable for the tropics - epoxy resin casted
Safety acc. to VDE, EN, UL, CSA

Technical data

Rated voltage: 250 VAC

Rated current: 16.0 A

Inductance: 2 x 4.8mH + 2 x 100µH

Capacity: 3 x 0.47µF + 4 x 22nF

Operating temperature range: -50°C / +85°C

Mounting: on rails acc. to DIN 46277 or wall mounting with screws

Dimensions (WxHxD): 64.0 x 100.0 x 120.0 mm

Weight: 1.10 kg
