Product information

Integrated cooling element
Reverse voltage protection
Thermal overload protection
Operating status shown by LED
Vibration proof
Suitable for the tropics - epoxy resin casted
Simple mounting on rail acc. to DIN 46277
Conforms to EMC and low voltage directive
Safety acc. to VDE, EN, UL, CSA

Technical data

Voltage range: 40-120 VDC

Input current: 2x 28 A

Outpur current: 1x 56 A

Operating temperature range: -40°C / +80°C

Mounting: on rails acc. to DIN 46277

Dimensions (WxHxD): 73.0 x 118.0 x 118.0 mm

Weight: 1.28 kg
