Product information

Output separated according to VDE 0551
Smoothed output
Extra low safety potential PELV (EN 60204), SELV (EN 60950)
Operating status shown by LED
Parallel connection possible
Suitable for the tropics - epoxy resin casted
Safety acc. to VDE, EN, UL, CSA

Technical dataInput voltage (VAC): 115 VAC / 230 VAC (45-66 Hz)

Output voltage: 110 VDC

Output current: 7.0 Amp

Power: 770.0 Watts

Efficiency: 90%

Residual ripple: < 2%

Operating temperature range: -30°C / +70°C

Mounting: wall mounting with screws

Dimensions (WxHxD): 171.0 x 224.0 x 215.0 mm

Weight: 17.00 kg
